Two components
Heat cure or Room temperature cure
Low viscosity
Flame retardant (UL approved File NO.E174951)
Non corrosive property to general metals
Good thermally conductivity
Flexible silicone rubber - from -40 to +180C
Excellent electrical properties
Applications
Encapsulation for electronic equipment and modules
Packing：20kg can, 200kg-drum Curing Condition：150sec./150C
How to use
The filler of KET-132-A/KET-132-B may have settled to the bottom of the container, so be sure to stir
thoroughly prior to use.
Measure KET-132-A/KET-132-B. The mix ratio is KET-132-A/KET-132-B = 100 : 100 by weight.
Stir until color is uniform.
De-air thoroughly.
Pour into area immediately.
KET-132-A/KET-132-B can be cured using the following recommended schedule 150sec./150C.
Storage precaution
Stored between 1～25℃, out of direct sunlight.
When KET-132-A/KET-132-B contact with inhibitors (ex. sulfur, phosphorus, nitrogen compounds, water,
organometallic salts, and so on), it may shows a defective cure.
KET-132-A/KET-132-B should not be used in high humid condition, as this may causes defective curing
and poor adhesion.
Completely remove water, oil, dirt and contaminants from the surface of the adherend.
For certain substrates, use a primer as needed.
Safety and hygiene
Uncured KET-132-A/KET-132-B may irritate skin and mucous membranes, so avoid eye contact and
prolonged skin contact. In case of accidental eye contact, flush with water for at least 15 minutes and see a
physician. In case of skin contact, immediately wipe off with a dry cloth and wash with soapy water. Contact
lens wearers should exercise adequate caution; if uncured KET-132-A/KET-132-B enters the eyes, the contact
lens may become bonded to the eye.
When using, be careful not to rub the eyes with the hands. Please take appropriate precautions such as
wearing safety glasses.
Make sure that work area is well ventilated. Be careful not to inhale vapors from the products used.
Keep out of reach of children.
For more information, please read the Material Safety Data Sheet (MSDS). You can receive an MSDS
from our Sales Department.
